GMM-60LY Remote control plate edge milling machine
Short Description:
GMM-60LY plate edge milling machine specially for plate edge beveling /milling/chamfering and clad removal for pre-welding. Available for plate thickness 6-60mm, bevel angel 0-90 degree. Max bevel width could reach 60mm. GMMA-60L with unique design available for Vertical milling and 90 degrees milling for transition bevel. Spindle adjustable for U/J bevel joint.
-
GMM-60LY Remote control plate edge milling machine
- Metal plate edge beveling milling machine mainly to do bevel cutting or clad removal / clad stripping /edge chamfering on steel plates material like mild steel, stainless steel, aluminum steel, alloy titanium,hardox,duplex etc.It is widely used for welding industry for welding preparation.
- GMM-60LY Remote control plate edge milling machine. Specially for plate edge beveling /milling/chamfering and clad removal for pre-welding. Available for plate thickness 6-60mm, bevel angel 0-90 degree. Max bevel width could reach 60mm. GMMA-60L with unique design available for Vertical milling and 90 degrees milling for transition bevel. Spindle adjustable for U/J bevel joint.
-
Bevel Joint and Bevel size for GMM-60LY Remote control plate edge milling machine
Proofing U-shaped groove
Titanium alloy material testing
-
Parameters for GMM-60LY china made plate edge milling machine
| Models | GMM-60LY plate edge milling machine |
| Power Suppy | AC 380V 50HZ |
| Total Power | 4520W |
| Spindle Speed | 1050r/min |
| Feed Speed | 0~1500mm/min |
| Clamp Thickness | 6~60mm |
| Clamp Width | >80mm |
| Clamp Length | >300mm |
| Bevel Angel | 0~90 degree |
| Singel Bevel width | 0-20mm |
| Bevel Width | 0-60mm |
| Cutter Diameter | Dia 63mm |
| Inserts QTY | 6 pcs |
| Worktable Height | 700-760mm |
| Suggest Table Height | 730mm |
| Worktable Size | 800*800mm |
| Clamping Way | Auto Clamping |
| Wheel Size | 4 Inch STD |
| Machine Height Adjust | Hydraulic |
| Machine N.Weight | 225 kgs |
| Machine G Weight | 260 kgs |
| Wooden Case Size | 950*700*1230mm |
- GMM-60LY Remote control plate edge milling machine standard packing list and wooden case packaging.
- Advantages for GMM-60L China made plate edge milling machine
- Automatic walking type beveling machine will walk along with plate edge for bevel cutting
- Beveling machines with universal wheels for easy moving and storage
- Cold cutting to avoid any oxide layer by using milling head and inserts for higher performance on surface Ra 3.2-6.3. It can do welding directly after bevel cutting. Milling inserts are market standard.
- Wide working range for plate clamping thickness and bevel angels adjustable.
- Unique design with reducer setting behands safer.
- Available for multi bevel joint type and easy operation.
- High efficiency beveling speed reach 0.4~1.2 meters per min.
- Automatic Clamping system and hand wheel setting for slight adjustment.
- Aplication for GMM-60LY Remote control plate edge milling machin
- Plate beveling machine are widely applicated for all welding industry. Such as
- 1) Steel Construction 2) Shipbuilding Industry 3) Pressure Vessels 4) Welding Manufacturing 5) Construction Machinery & Metallurgy
- Site performance picture for reference by GMM-60LY Remote control plate edge milling machine
- GMMA-60LY plate edge milling machine is a economic option with wide working range. The most selling models from begining until now more than 10 years. We are updating machines every year to improve the machine quality. It can fully meeting regular bevel requirements. Also available to do specially bevel U/J type joint , vertical milling and 90 degree milling.
- Normally customer will facing option between GMMA-60LY and GMMA-100LY plate edge milling machine . Both model with exactly same function. GMMA-60LY is L size, Then GMMA-100LY is XL size for heavy duty plates
